Mower Gearbox

Mower Gearbox
Details:
The XH21 rotary mower gearbox is specified for a 21 HP drive with a 540 rpm input. It connects the mower driveline to the cutting assembly through the output shaft shown in the technical drawing. The two listed ratios, 1:2.83 and 1:2.5, give equipment builders a choice when matching the gearbox to the speed required by the mower drive.
The 1:2.83 configuration is listed as XH21.283Z.01L on the product page. The catalogue drawing identifies XH21.283Z.01 and lists 94 Nm of output torque and a 1 3/8 inch Z6 input spline. The 1:2.5 option is listed as XH21.250Z.01L. Each website configuration has a listed weight of 15 kg.
Send Inquiry
Description
Send Inquiry

Key Features



  • 21 HP input power and 540 rpm input speed for the two listed configurations.
  • Choice of 1:2.83 or 1:2.5 ratio by complete configuration code.
  • Original 283Z drawing shows the shaft positions and mounting pattern.



Product Applications



Use the XH21 when specifying the drive for a rotary mower or sourcing a replacement for an existing unit. Start with the mower's required ratio, then check the input coupling, output hub and deck mounting pattern against the drawing for the selected configuration. For the 1:2.5 option, request its own interface drawing before finalizing the mower assembly.



Technical Specifications



Parameter

Catalogue configuration

Model

XH21.283Z.01

Website reference

XH21.283Z.01L

Application

Rotary mower

Input power

21 HP

Input speed

540 rpm

Ratio

1:2.83

Output torque

94 Nm

Input spline

1 3/8 inch Z6

Website weight

15 kg for the listed .01L configuration

Additional website option

XH21.250Z.01L, 21 HP, 1:2.5, 540 rpm, 15 kg. Request the drawing for this configuration.



Product Design



The original sheet combines three dimensioned views with a gear arrangement symbol. These define the relative position of the input and output and the attachment geometry. The .283Z.01 technical sheet provides the reference for that illustrated arrangement; additional suffixes and ratio versions should be identified explicitly in the order specification.



Original Technical Sheet



Configuration codes and dimensions remain as published:

product-1684-2382

Frequently Asked Questions



Q: Which ratio should be named in an XH21 sample enquiry?

A: Identify whether the mower needs the catalogue 1:2.83 configuration or the separately listed 1:2.5 option. Include the existing identification plate so the enquiry does not mix the two references.

Q: How should a mower OEM specify XH21 for a new deck?

A: Send the mower deck mounting drawing, the driveline connection and the cutting assembly hub dimensions with the complete XH21 configuration code. Include the selected ratio and any required shaft clearances so the gearbox interfaces can be reviewed together.

Q: Can an alternative output shaft be requested?

A: Provide the required output shaft profile, engagement length and mating hub drawing. A proposed change should be reviewed against the 283Z technical sheet, with the approved configuration identified in the quotation.

Q: What should the inspection record include for the 283Z unit?

A: Record the ordered code, 1:2.83 ratio, input spline and mounting dimensions. If a sample is used for fit checking, document the mating hub and mower plate used in that evaluation.

Q: What information helps obtain support for a mower installation?

A: Send the full code, ratio and photographs of the mower mounting plate and hub. State the actual input speed so the installation can be compared with the catalogue's 540 rpm condition.



Enquiry Information

Include the complete model and configuration, machine application, selected ratio, input speed and mating component drawings with an enquiry. Sample supply, OEM identification, customization scope, inspection documents and service arrangements are addressed in the quotation or order agreement for the specified configuration.
