Bladder Type Pulsation Dampeners
Compound;Temp.Limits Suitable Applications Buna-N:-12℃～+82℃Use with petroleum solvents and oil-based fluids Butyl:-9℃～+70℃ Use with nitric acid,oxygen,ozone,propagation,grease,fatty acid
TYPE | MATERIALS | CAPACITY(L) | PRESSURE(MPA) | SIZE | CONNECTIONS | |||
H(mm) | L1(mm) | L2(mm) | D(mm) | |||||
HLMZ-QP0.4/1.0 | Plastic | 0.4 | 1.0 | 315 | 130 | 52 | 90 | Rc 3/4“ |
HLMZ-QP0.63/1.0 | Plastic | 0.63 | 1.0 | 365 | 180 | |||
HLMZ-QP1.0/1.0 | Plastic | 1.0 | 1.0 | 470 | 282 | |||
HLMZ-QP1.6/1.0 | Plastic | 1.6 | 1.0 | 400 | 190 | 65 | 160 | Rc 11/4“ |
HLMZ-QP2.5/1.0 | Plastic | 2.5 | 1.0 | 470 | 260 | |||
HLMZ-QP4.0/1.0 | Plastic | 4.0 | 1.0 | 580 | 370 | |||
HLMZ-QP6.3/1.0 | Plastic | 6.3 | 1.0 | 750 | 540 | |||
HLMZ-QP10/1.0 | Plastic | 10 | 1.0 | 710 | 460 | 90 | 225 | Rc 2“ |
HLMZ-QS0.4/20 | Stainless Steel | 0.4 | 20 | 320 | 135 |
52 |
89 |
M27X2-6H |
HLMZ-QS0.63/20 | Stainless Steel | 0.63 | 20 | 375 | 190 | |||
HLMZ-QS1.0/20 | Stainless Steel | 1.0 | 20 | 485 | 300 | |||
HLMZ-QS1.6/20 | Stainless Steel | 1.6 | 20 | 420 | 210 |
65 |
152 |
M42X2-6H |
HLMZ-QS2.5/20 | Stainless Steel | 2.5 | 20 | 490 | 280 | |||
HLMZ-QS4.0/20 | Stainless Steel | 4.0 | 20 | 600 | 390 | |||
HLMZ-QS6.3/20 | Stainless Steel | 6.3 | 20 | 770 | 560 | |||
HLMZ-QS10/20 | Stainless Steel | 10 | 20 | 740 | 490 | 90 | 219 | M60X2-6H |
Compound | Temp.Limits | Suitable Applications |
Buna-N | -12℃～+82℃ | Use with petroleum solvents and oil-based fluids |
Butyl | -9℃～+70℃ | Use with nitric acid,oxygen,ozone,propagation,grease,fatty acid |
Viton | -23℃～+137℃ | Use in hot fluids;goods with acids,armatics and oil |
EPDM | -51℃～+137℃ | Use in extreme cold;goods with caustics,ketone,salt |
PTFE | +4℃～+104℃ | Use in hot and aggressive fluids excellently |
Shell Materials:
Plastic: PP、UPVC、PVDF、PTFE
Metal:304L、316L、Carbon steel 、Aluminium、Hastelloy C
